Hafele Salice by Hafele Concealed Undermount Full Extension Slide, 66 lbs, 12″ to 24″ with Touch Release
- SKU: N/A
- Brand: Hafele
$31.62 – $41.18
refund
On orders over $99
- Concealed Undermount Pair Rated to Support up to 66 lbs.
- Requires Mounting Clip
- Euro 32mm Hole Pattern
- Touch Release allows for drawers with out handles or pulls
- 2.5mm height adjustment
- Front Clip Disconnect
- For Frameless Cabinetry Only
- Requires Flat Head #6 Mounting Screws
The Salice Futura Push 6775 by Hafele is designed for a wide range of light to medium duty drawer applications, offering depth and height adjustment for easy installation. With touch release you can press gently on the drawer face to have it pop open, eliminating the need for handles and pulls. The Futura Push 6775 brings a unique style to your home, all while hiding out of sight under your drawer boxes.
Dimensions:
(W = side to side) (D = front to back) (H = top to bottom)
Top Clearance: 3/16″+ (5mm+)
Bottom Clearance: 11/16″ – 7/8″ (16.5mm – 21.5mm)
Depth Clearance: 3/8″+ (10mm+)*
*For 22 and 24″ Slides, 3/16″+ (5mm+)
Side Clearance Details:
Drawer Box Side Thickness |
5/8″ (16mm) | 19/32″ (15mm) | 9/16″ (14mm) | 1/2″ (13mm) | 15/32″ (12mm) |
---|---|---|---|---|---|
Drawer Box Side Clearance |
3/8″ (9mm) | 7/16″ (11mm) | 1/2″ (13mm) | 5/8″ (16mm) | 21/32″ (17mm) |
Weight | N/A |
---|---|
Dimensions | N/A |
Attachments | Detailed Specifications |
Brand | |
Length | (16") 400 mm, (22") 550 mm, (24") 600 mm, 12'' (300mm), 14'' (350mm), 18'' (450mm), 20'' (500mm) |
Download PDF
