Hafele Concealed Undermount Full Extension Slide, 75 lbs, 12″ to 21″ with Soft Close
$23.09 – $25.42
Clearance – Limited Quantities Available
Features:
- Concealed Undermount Slide Pair Rated to support 75 lbs.
- Requires Mounting Clips & Mounting Bracket
- Designed for use on Drawer Boxes with 3/8″ – 3/4″ Thick Walls
- Optional Disconnect Levers
- Optional Face Frame Mounting Brackets offer 1-3/8″ of depth adjustment
- Minimum Clearance: 7/16″W x 3/8″D x 13/16″H
- Requires Varianta-5 Screws (available at checkout)
Description:
The Full Extension Concealed Undermount Slides by Hafele are a group of medium duty slides designed for most common cabinet drawers. A pair of disconnect levers allow you to easily remove the drawer box from its cabinet with a simple press. With an integrated Soft and Silent Mechanism, these slides resist slamming by forcing the drawer to slow down right before closure.
Dimensions:
(W = side to side) (D = front to back) (H = top to bottom)
Top Clearance: 1/4″+ (6mm+)
Bottom Clearance: 9/16″ (15mm)
Rear Clearance: 3/8″ – 1-3/4″ (10mm – 45mm)
Side Clearance Details:
| Drawer Wall Thickness |
3/4” (19mm) | 23/32” (18mm) | 21/32” (17mm) | 5/8” (16mm) | 19/32” (15mm) |
|---|---|---|---|---|---|
| Total Required Side Clearance |
7/16” (11mm) | 15/32” (13mm) | 9/16” (14mm) | 21/32” (17mm) | 3/4” (19mm) |
Face Frame Mounting Bracket offers 1-3/8″ (35mm) of depth adjustment
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Length | 12'', 15'', 18'', 21'' |
| Brand |
Download PDF
