- For very narrow reveals
- Full overlay (16 mm cabinet side), reveal 3 mm
- Reveal 3 mm
- Tool-free clip fitting of door
- Cup edge cover
- Side adjustment -2 mm
- Height adjustment ±2 mm via slots
- Visible joint
- Material: Steel
- Color/Finish: Nickel
- Mounting Type: Frameless
- Crank: 13 mm
- Type: Hinge Arm
- Standards and Certifications: ANSI/BHMA A156.9-2003
- Hinge Opening Angle: +270°
Important information:
Hinge arms and cups have to be ordered separately.
