Hafele Concealed Undermount 3/4 Extension Slide, 66 lbs, 8-9/16″ to 15-7/8″ with Lock In
- SKU: N/A
- Brand: Hafele
$12.47 – $15.09
refund
On orders over $99
Features:
- Concealed Undermount Slide Pair rated to Support up to 66 lbs.
- Material: Steel
- For Drawers with Walls between 1/2″ and 5/8″ Thick
- Stay closed feature for holding in closed position
- 1/8″ Height Adjustment with wheel nut
- Slotted Mounting Holes for Depth Adjustment
- Front Clip Disconnect
- Minimum Drawer Clearance: 5/16″W x 3/8″H
- Requires Varianta 5 Screws (Available at Checkout)
Description:
The Hafele Single Extension Self Closing Drawer Slides for Frameless Cabinetry include several features desgined to make the most of a budget slide. With a large height adjustable wheel, you can easily bring your drawer boxes to a level position. These concealed undermount drawer slides stay hidden from view, a common request in modern sliding hardware.
Dimensions:
(W = side to side) (D = front to back) (H = top to bottom)
Drawer Box Material Thickness: 1/2″ – 5/8″ (12mm – 16mm)
Required Bottom Clearance: 13/32″+ (10.5mm+)
Required Side Clearance Depends on Material Thickness:
Drawer Box Side Thickness |
5/8″ (16mm) | 19/32″ (15mm) | 9/16″ (14mm) | 1/2″ (13mm) | 15/32″ (12mm) |
---|---|---|---|---|---|
Drawer Box Side Clearance |
3/8″ (9mm) | 7/16″ (11mm) | 1/2″ (13mm) | 5/8″ (16mm) | 21/32″ (17mm) |
Weight | N/A |
---|---|
Dimensions | N/A |
Attachments | Detailed Specifications |
Brand | |
Length | 352 mm, 402 mm, 452 mm, 502 mm |
Drawer Length | 350 mm, 400 mm, 450 mm, 500 mm |
Download PDF
