Grass by Hafele Concealed Undermount Soft Close Full Extension Slide, 132 lbs Weight Capacity
- SKU: N/A
- Brand: Hafele
$95.40 – $158.15
refund
On orders over $99
Features:
- Concealed Undermount Slide Pair for Frameless Cabinetry
- Full extension
- Weight capacity: 132 lbs. (60kg)
- Built in 3D adjustment (Height, side, and tilt)
- Requires R/L front locking device and R/L rear adjustment adapter (See Required Accessories)
- Integrated Soft Close air dampening provides the lowest possible resistance when opening
- Fully synchronized runner for the ultimate in smooth silent operation
- Continuous self-locking of drawer when pushed onto the drawer
- Slide-on mounting
- Progressive Movement Smooths out extension and retraction motion
- Designed for drawer boxes up to 5/8″ wall thickness
- Minimum Drawer Clearance: 3/8″W x 7/8″D x 11/16″H
- Requires Varianta-3 or #8 PanHead Mounting Screws (See Accessories)
Description:
The Grass DynaPro 16 HD by Hafele is a Heavy Duty slide, designed to support up to 110 lbs. With 3D adjustment built in, you can tweak the slides’ height, side clearance, and tilt on the fly, ensuring your drawer faces will line up as perfectly as you need. Progressive movement and a Continious Self Locking mechanism allows these slides to more smoothly extend and retract, while a soft close system slows down your drawer while closing to prevent slamming.
Dimensions:
(W = side to side) (D = front to back) (H = top to bottom)
Item No. | Drawer Length | Min. Installation Depth |
---|---|---|
433.20.448 | 18” (457mm) | 18-7/8” (479mm) |
433.20.456 | 21” (533mm) | 21-7/8” (555mm) |
433.20.464 | 24” (610mm) | 24-7/8” (632mm) |
433.20.471 | 27” (686mm) | 27-7/8” (708mm) |
433.20.479 | 30” (762mm) | 30-7/8” (784mm) |
Weight | N/A |
---|---|
Dimensions | N/A |
Slide Length | 18'', 21'', 24'', 27'', 30'' |
Brand |
