Hafele Grass Dynapro 16 Tipmatic Full Extension Slide – 88 lbs. Load Capacity
- SKU: N/A
- Brand: Hafele
$93.95 – $98.05
refund
On orders over $99
- Hafele Grass Dynapro 16 Tipmatic Full Extension Slide
- Material: Steel
- Finish: Zinc
- Front left/right locking devices required for installation
- Applicable for face frame or frameless applications
- Tipmatic mechanism provides push-to-open functionality
- Fully synchronized runner for superior smooth, silent operation
- Side to side, height and tilt adjustment for perfect drawer alignment
- Continuous self-locking mechanism activates when pushed onto the drawer
- Load Bearing Capacity: 88 lbs. (40 kg)
- Slide-on mounting
- Meets or exceeds BHMA Grade 1 testing requirements
- Slides sold individually
Item No. | Drawer Length | Min. Installation Depth | Max. Installation Depth |
---|---|---|---|
433.19.905 | 15” (381mm) | 15-7/8” (403mm) | 17-9/16” (446mm) |
433.19.908 | 18” (457mm) | 18-27/32” (479mm) | 20-9/16” (522mm) |
433.19.911 | 21” (533mm) | 21-27/32” (555mm) | 23-17/32” (598mm) |
Weight | N/A |
---|---|
Dimensions | N/A |
Length | 15'' (381mm), 18'' (457mm), 21'' (533mm) |
Brand |
Download PDF
