Hafele Double-Wall Drawer System Frame, Drawer side height 90 mm, Nova Pro Scala
$40.02 – $45.80
refund
On orders over $99
- Elegant continuous design formed from a single piece of high quality steel
- Synchronized full extension drawer slide
- Smooth soft closing with state-of-the-art technology
- Integrated height and side adjustment
- Drawer front can be installed or removed without tools
- Works with Tipmatic soft close and Sensomatic touch-to-open systems
- Bottom and back panel width are the same
- 2 and 3 dimensional adjustments
- Vertical interior walls for optimum use of interior space
- Height: Side: (3 1/2″) 90 mm
Features:
Standard height for all applications
Load bearing capacity
(88 lbs) 40 kg and (154 lbs) 70 kg dynamic
Weight | 2 lbs |
---|---|
Finish | Ice, Stone |
Length | 300 mm, 350 mm, 400 mm, 450 mm, 500 mm, 550 mm |
Brand | |
Attachments | Nova Pro Adjustments, Nova Pro Instructions |
Download PDF
Download PDF
