Contemporary Finger Grip Handle for 3/4″ Panel – 3187

SKU: N/A

$93.24$121.02

Ideal for top and bottom cabinet doors, and can also be used for drawer fronts.
Can be cut to required length and installed using glue (not included).

Clear
Categories: ,

Description

  • Pulls and Knobs Style: Modern
  • Type: Aluminum and wood profiles
  • Material: Anodized Aluminum
  • Thickness: 21.5 mm
  • Visible Height: 12.5 mm
  • Panel Thickness: 3/4 to 25/32 in
  • Barb Thickness: 3.3 mm
  • Depth of Groove: 13 mm
  • Length – Overall Dimensions: 12 ft
  • Color Group: Gray and Chrome Group
  • Model: Industrial
  • Projection – Overall Dimensions; 22.5 mm

Advantages and Benefits

– Takes up no space in front of your doors, ideal for smaller spaces
– Easy-to-clean rounded design

Application

Kitchens, bathrooms, office furniture, laundry rooms, hotels, laboratories, hospitals, clinics.

Important Information

We strongly recommend that you order the products TUBECART and CAP (two CAPs per TUBECART) to package this product. No packaging fees when ordered by the complete case. Returns or claims for unpackaged products will not be accepted. Feel free to contact us at info@richelieu.com with questions.

Disclaimer

Exclusion from responsibility: Picture for visual reference only: actual product may vary from that shown in photo. The dimensions and finish may vary due to manufacturing methods. All technical drawings and documents contain examples for the assembly of different supplier hardware. The preceding information as well as any technical recommendations given in writing, verbally or based on tests are provided to the best of our knowledge. However, they are non-binding recommendations only and do not affect your responsibility to determine the correctness of given recommendations and suitability of the product for your particular purposes. The application, use or processing of our products as well as the production of products based on our technical recommendations are beyond our control and therefore fall exclusively in your area of responsibility. Sales of our products are effected according to our most updated General Sales and Delivery Conditions.
Technical documentation click here
Technical documentation click here
Weight 1 lbs
Finish

Satin Aluminum, Stainless Steel

Brand

Attachments

Finger Grip Handle
